Cooler Master V750 SFX Gold Power Supply User Manual

Pêşkêş

The Cooler Master V SFX Gold power supply delivers high-performance power in a compact SFX form factor, ideal for mini-ITX builds. It features 80 Plus Gold efficiency, full-modular cabling, a Fluid Dynamic Bearing (FDB) fan, and 16AWG PCIe high-efficiency cables. This unit is designed for reliable and efficient power delivery to your PC components.

Product Overview

The V750 SFX Gold power supply is engineered for optimal performance and compatibility with various PC builds, especially those requiring a smaller footprint.

Wêne 1: Pêşî view of the Cooler Master V750 SFX Gold power supply, highlighting its modular cable connections.

Figure 2: Size comparison illustrating the compact "Mighty ITX Design" of the SFX power supply compared to a standard ATX power supply.

Wêne 3: Ji nêzîk ve view of the fully modular connection ports on the power supply, labeled for different cable types (M/B, PCIe/CPU, HDD/SATA).

Figure 4: Rear panel of the power supply, showing the main power input, on/off switch, and ventilation.

Figure 5: Exploded diagram illustrating the internal components, including the fan, casing, and circuit board.

Sazkirin û Sazkirin

Follow these steps to properly install your Cooler Master V750 SFX Gold power supply into your system.

1. Mounting the Power Supply

The V SFX Gold is designed to fit perfectly in mini-ITX cases. Use the included bracket for compatibility with various system sizes. Secure the power supply in the designated PSU bay of your PC case using the provided screws.

2. Girêdana Cables

This power supply features a fully modular design, allowing you to connect only the cables you need, reducing clutter and improving airflow. Identify the necessary cables for your motherboard, CPU, GPU, and storage devices.

• MB 24-pin: Connects to the main motherboard power port.
• CPU 4+4 pin / CPU 8 pin: Connects to the CPU power port on the motherboard.
• PCI-e 6+2 pin: For graphics cards requiring PCIe power.
• 12V-2x6 (12VHPWR): Specifically for modern high-power GPUs, delivering up to 450W. This cable features a 90° connector for improved durability and safety.
• Peripheral 4 pin: For older peripherals or fan controllers.
• SATA 15 pin: For SATA hard drives, SSDs, and optical drives.

Wêne 6: Serview of the customized cable lengths provided with the power supply, designed to reduce clutter in compact cases.

Figure 7: Detail of the 90° 12VHPWR PCIe 5.1 connector, designed for enhanced durability and thermal performance.

Figure 8: The power supply with the ATX 3.1 12VHPWR cable connected, ready to deliver up to 450W to a GPU.

3. Hêzdarkirin

Once all connections are secure, connect the main power cord to the power supply and a wall outlet. Flip the power switch on the back of the power supply to the 'ON' position. Your system is now ready to be powered on.

Prensîbên Xebatê

The Cooler Master V750 SFX Gold operates with high efficiency and advanced thermal management to ensure stable and reliable power delivery.

80 Plus Gold Efficiency

This power supply is 80 Plus Gold certified, meaning it achieves 90% efficiency at typical loads (50% load at 230V). This high efficiency minimizes wasted energy as heat, leading to lower operating temperatures and reduced electricity bills.

Figure 9: Graph illustrating the 80 Plus Gold efficiency curve, showing performance at different load percentages for 115V and 230V inputs.

Kondansatorên Japonî

The V750 SFX Gold utilizes high-quality 100% Japanese capacitors, which contribute to improved efficiency and reduced ripple noise, ensuring stable and clean power output.

Figure 10: Illustration highlighting the high-quality Japanese capacitors used in the power supply for enhanced reliability.

High Power Density

With a power density of 15.5W/IN³, the V750 SFX Gold offers significant power output in a small volume, making it highly efficient for compact builds.

Figure 11: Diagram illustrating the high power density of the V750 SFX Gold, showing 15.5W/IN³.

Lênerrînî

Parastina rast temenê dirêj û performansa çêtirîn a dabînkirina hêza we garantî dike.

Fluid Dynamic Bearing (FDB) Fan

The 92mm FDB fan provides reliable and efficient cooling with a self-lubricating design, requiring minimal maintenance. Keep the fan intake and exhaust areas clear of dust and obstructions to ensure proper airflow.

Figure 12: Specifications of the 92mm Fluid Dynamic Bearing fan, including speed, airflow, and noise level.

Paqijî

Periodically clean the exterior of the power supply and the fan grille using a soft, dry cloth. For internal cleaning, it is recommended to use compressed air to remove dust from the heatsinks and fan blades. Always disconnect the power supply from the wall outlet and your system before cleaning.

Çareserkirina pirsgirêkan

Heke hûn bi pirsgirêkên dabînkirina hêza xwe re rû bi rû bimînin, gavên çareserkirina pirsgirêkên hevpar ên jêrîn bifikirin:

• Hêz tune: Ensure all cables are securely connected, including the main power cord to the wall outlet and the power supply. Check the power switch on the back of the PSU is in the 'ON' position.
• Bêîstîqrariya Sîstemê: Verify that your power supply wattage is sufficient for all your components. Ensure all modular cables are fully seated into both the power supply and the respective components.
• Dengên neasayî: Check for any loose screws or components inside your PC case. If the fan is making excessive noise, ensure it is free from obstructions.
• Zêde germbûn: Ensure adequate airflow within your PC case. Check that the power supply's fan is spinning freely and not obstructed.

If problems persist after basic troubleshooting, consult the Cooler Master support webmalperê an jî ji bo alîkariya bêtir bi karûbarê xerîdar a wan re têkilî daynin.

Specifications

Garantî û Piştgirî

Cooler Master provides a 10-year warranty for the V750 SFX Gold power supply, ensuring long-term reliability and peace of mind. For detailed warranty terms and conditions, please refer to the official Cooler Master webmalper an karta garantiyê ya ku tê de ye.

For technical support, product registration, or to download the latest drivers and software, please visit the official Cooler Master support page. You can also find additional resources and FAQs on their Amazon Store.

Planên parastinê ji bo berfirehkirina bergiriyê jî hene:

• Plana Parastinê ya 3-Salî
• Plana Parastinê ya 4-Salî
• Parastina Tevahî (plana mehane ya ku kirînên mafdar vedihewîne)

For the official user manual in PDF format, please refer to this girêk.
